WindO/I-NV4 User’s Manual 31-23
2 USB Autorun Function
31
External Memory Devices
2.2 USB Autorun Function Configuration Procedure
● Executing commands using the USB Autorun function
Configuration Procedure
1 On the Configuration tab, in the System Setup group, click Project.
The Project Settings dialog box appears.
2 On the Autorun tab, select the Enable USB Autorun check box and click OK.
For details, refer to Chapter 4 “3.10 Autorun Tab” on page 4-64.
3 Create a USB Autorun definition file (hgauto.ini) and save it on the USB flash drive.
For details, refer to “2.3 Creating a USB Autorun Definition File” on page 31-26.
• If the USB Autorun function of the MICRO/I is not enabled, the menu screen will not be displayed, even if
a USB flash drive is inserted into the MICRO/I.
• Once the USB Autorun function of the MICRO/I is enabled, the function will remain enabled until either a
project with the Enable USB Autorun check box unchecked is downloaded, or the function is disabled
via the System Mode.
When enabling the USB Autorun function using the MICRO/I, on the Top Page in the System Mode, press
Main Menu, Initial Setting, System Operation (for HG4G/3G/2G-5F) or System Op. (for HG2G-5T,
HG1G), and then press Autorun.
Save
Computer
USB flash drive
USB Autorun
definition file
(hgauto.ini)
To Next Page
