WindO/I-NV4 User’s Manual 27-1

Pass-Through Function

This chapter describes the overview of the Pass-through function, it's configuration and other important details.

1.1 How the Pass-Through Function is Used

The Pass-through function downloads or uploads a PLC program from a computer or an external device via the

MICRO/I.

Chapter 27 Pass-Through Function

1 Overview

HG3G

HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T

HG4G HG1G HG1P

HG2J-7U

Computer

MICRO/I

130

External device

Device Link Communication

Pass-Through Communication

Read

Write

Read

Write

PLC programming

software
