3 Multimedia Settings Dialog Box
22-12 WindO/I-NV4 User’s Manual
This section describes items and buttons on the Multimedia Settings dialog box.
3.1 Multimedia Settings Dialog Box
● Movie Tab
Create and edit a list of movie files to be used with project data.
Based on the contents that have been set a movie file list, “MOVIE.LST”, is automatically created in the root folder of
the External Memory Device folder in the external memory device.
■ Movie File List:
Displays a list of movie files to be used with project data.
*1 avi for HG5G/4G/3G-V, mp4 for HG4G/3G
3 Multimedia Settings Dialog Box
HG3G
HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T
HG4G HG1G HG1P
HG2J-7U
ID: Displays the movie file list ID.
File Path: Displays the file path of the movie file.
Click the cell, and then enter the file path of a movie file. The maximum number is 250
characters. Only alphanumeric characters and symbols can be used.
To specify a movie file saved in the "MOVIE" folder in the External Memory Device folder
configured on the External Memory Device tab in the Project Settings dialog box, only
enter the file name.
Example: When the name of the External Memory Device folder is "HGDATA01"
Enter "sample01" and the file name is:
A:\HGDATA01\MOVIE\sample01.file extension
*1
Click the cell, and then click to display the Open dialog box. Then specify a movie file with
the Open dialog box.
You cannot use the following characters in the file path.
" * , / : ; < > ? |
However, a colon (:) can be used to indicate a drive letter, such as "A:".
To Next Page
