WindO/I-NV4 User’s Manual 22-13

3 Multimedia Settings Dialog Box

Multimedia Function

■ Delete

Deletes movie files from the movie file list.

Select a movie file from the movie file list and then click this button.

■ Up

Shifts the selected movie file upward on this list.

■ Down

Shifts the selected movie file downward on this list.

■ Import

Imports an exported movie file list.

Existing movie file lists will be overwritten.

■ Export

Exports a movie file list with the file name “MOVIE.LST”.

Even if the file path of a movie file is deleted from the movie file list, the movie file itself will not be deleted.
