1 Overview
30-2 WindO/I-NV4 User’s Manual
1.2 Applicable Expansion Modules
● Digital I/O Module
IDEC MicroSmart PLC Digital I/O module that can be attached as expansion modules are shown below.
■ Digital Input Modules
■ Digital Output Modules
HG3G
HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T
HG4G HG1G HG1P
HG2J-7U
Type Model No. Terminal
Dimensions
(L x W x H (mm))
Consumption
Current (mA)
HG5G/
4G/3G/
2G-V
HG4G/
3G
HG2G-
5F
5 V 24 V
8 points/AC Input FC4A-N08A11
Removable
Screw terminal
block
90.0×23.5×70.0 25 0 NO YES YES
8 points/DC Input FC4A-N08B1 90.0×23.5×70.0 25 0 NO YES YES
16 points/DC Input FC4A-N16B1 90.0×23.5×70.0 40 0 NO YES YES
16 points/DC Input FC4A-N16B3
MIL Connector
90.0×17.6×70.0 35 0 NO YES YES
32 points/DC Input FC4A-N32B3 90.0×29.7×70.0 65 0 NO YES YES
8 points/AC Input FC6A-N08A11
Removable
Screw terminal
block
90.0×23.6×73.0 40 0 YES YES YES
8 points/DC Input FC6A-N08B1 90.0×23.6×73.0 30 0 YES YES YES
16 points/DC Input FC6A-N16B1 90.0×23.6×73.0 40 0 YES YES YES
16 points/DC Input FC6A-N16B3
MIL Connector
90.0×17.6×73.0 40 0 YES YES YES
32 points/DC Input FC6A-N32B3 90.0×30.2×73.0 65 0 YES YES YES
8 points/AC Input FC6A-N08A14
Removable
Push-in
terminal block
90.0×30.2×73.0 40 0 YES YES YES
8 points/DC Input FC4A-N08B4 90.0×30.2×73.0 30 0 YES YES YES
16 points/DC Input FC4A-N16B4 90.0×30.2×73.0 40 0 YES YES YES
Type Model No.
Terminal
Dimensions
(L x W x H (mm))
Consumption
Current (mA)
HG5G-
V
HG4G/
3G/2G
-V
HG4G/
3G
HG2G-
5F
5 V 24 V
8 points/Relay Output
FC4A-R081
Removable
Screw
terminal
block
90.0×23.5×70.0
30 40 NO NO YES YES
16 points/Relay Output
FC4A-R161
90.0×23.5×70.0
45 75 NO NO YES YES
8 points/Transistor Sink Output
FC4A-T08K1
90.0×23.5×70.0
10 20 NO NO YES YES
8 points/Transistor Source Output
FC4A-T08S1
90.0×23.5×70.0
10 20 NO NO YES YES
16 points/Transistor Sink Output
FC4A-T16K3
MIL
Connector
90.0×17.6×70.0
10 40 NO NO YES YES
16 points/Transistor Source Output
FC4A-T16S3
90.0×17.6×70.0
10 40 NO NO YES YES
32 points/Transistor Sink Output
FC4A-T32K3
90.0×29.7×70.0
20 70 NO NO YES YES
32 points/Transistor Source Output
FC4A-T32S3
90.0×29.7×70.0
20 70 NO NO YES YES
8 points/Relay Output
FC6A-R081
Removable
Screw
terminal
block
90.0×23.6×73.0
35 50 YES YES YES YES
16 points/Relay Output
FC6A-R161
90.0×23.6×73.0
50 100 NO YES YES YES
8 points/Transistor Sink Output
FC6A-T08K1
90.0×23.6×73.0
25 15 YES YES YES YES
8 points/Transistor Source Output
FC6A-T08S1
90.0×23.6×73.0
25 15 YES YES YES YES
16 points/Transistor Sink Output
FC6A-T16K1
90.0×23.6×73.0
30 25 YES YES YES YES
16 points/Transistor Source Output
FC6A-P16K1
90.0×23.6×73.0
30 25 YES YES YES YES
16 points/Transistor Sink Output
FC6A-T16K3
MIL
Connector
90.0×17.6×73.0
30 25 YES YES YES YES
16 points/Transistor Source Output
FC6A-P16S3
90.0×17.6×73.0
30 25 YES YES YES YES
32 points/Transistor Sink Output
FC6A-T32K3
90.0×30.2×73.0
45 50 YES YES YES YES
32 points/Transistor Source Output
FC6A-P32S3
90.0×30.2×73.0
45 50 YES YES YES YES
8 points/Relay Output
FC6A-R084
Removable
Push-in
terminal
block
90.0×23.6×73.0
35 50 YES YES YES YES
16 points/Relay Output
FC6A-R164
90.0×23.6×73.0
50 100 NO YES YES YES
8 points/Transistor Sink Output
FC6A-T08K4
90.0×23.6×73.0
25 15 YES YES YES YES
8 points/Transistor Source Output
FC6A-T08P4
90.0×23.6×73.0
25 15 YES YES YES YES
16 points/Transistor Sink Output
FC6A-T16K4
90.0×23.6×73.0
30 25 YES YES YES YES
16 points/Transistor Source Output
FC6A-T16P4
90.0×23.6×73.0
30 25 YES YES YES YES
To Next Page
