WindO/I-NV4 User’s Manual 18-9
3 Recipe Settings Dialog Box
18
Recipe Function
■ Edit
Registers or changes the settings for the selected number.
Select a number in Settings and click this button to display the Individual Settings dialog box. The settings for the
selected channel are reflected in the Individual Settings dialog box.
For details, refer to “3.2 Individual Settings Dialog Box” on page 18-10.
■ Save Recipe Files to External Memory Device
Saves all the settings in every channel on the Recipe Settings dialog box to the external memory device as a recipe
file.
Click this button to display the Select Drive dialog box.
Only saves channels configured with Access to set to External Memory Device and Recipe Function set to
Enable.
Recipe Name: Shows the name of the Recipe function for each channel. Double clicking the cell displays the
Individual Settings dialog box. For details, refer to “3.2 Individual Settings Dialog Box” on
page 18-10.
Top Device Address: Shows the start device of the destination device addresses for recipe values and the source
device addresses for values of device addresses. Double clicking the cell displays the Tag Editor.
For the device address configuration procedure, refer to Chapter 2 “5.1 Device Address Settings”
on page 2-70.
This option can only be configured when Recipe function is Enable.
Data Type: Shows the data type of the values of source or destination device addresses. Double clicking the
cell displays the Individual Settings dialog box. For details, refer to “3.2 Individual Settings
Dialog Box” on page 18-10.
No. of Data: Shows the number of source or destination device addresses starting with the device address
configured by Top Device Address. Double clicking the cell displays the Individual Settings
dialog box. For details, refer to “3.2 Individual Settings Dialog Box” on page 18-10.
Display Type: Shows the display type of Data in Data List configured on the Data tab in the Individual
Settings dialog box. Double clicking the cell displays the Individual Settings dialog box. For
details, refer to “3.2 Individual Settings Dialog Box” on page 18-10.
To register or edit multiple numbers as a group, press and hold SHIFT or CTRL while you click the specific
items to select multiple lines and click Edit. The details configured on the Individual Settings dialog box
are collectively configured.
To Next Page
