5 Key Button
8-94 WindO/I-NV4 User’s Manual
5.4 Key Buttons
● For Keypad(Half-Width Character)
These keys can be used for Numerical Input and Character Input:
■ Numerical Input Keypad
■ Character Input Keypad
Key Operation
. Inputs a decimal point.
0 to 9 Inputs a number from 0 to 9.
A to F Inputs a character from A to F.
+/- Toggles the sign.
CAN
Clears the data input thus far and cancels the input. Closes the Popup Screen that is opened as
the Keypad, if this key is placed on it.
CLR Clears the data input thus far and stands by for further input.
BS Deletes the character to the left of the character at the cursor position.
ENT
Writes the characters input as a numeric value to a device address. After the data is written, the
focus can be moved according to the Focus Order setting. Focus Order can be set on the
Options tab of the Screen Properties dialog box.
< Fcs.
Moves the focus one item before the current one as per the Focus Order setting. Focus
Order can be set on the Options tab of the Screen Properties dialog box.
Fcs. >
Moves the focus one item after the current one as per the Focus Order setting. Focus Order
can be set on the Options tab of the Screen Properties dialog box.
Alt
The Alt key switches the Popup Screen opened as a Keypad. Closes the Popup Screen that is
opened as the Keypad and opens another Popup Screen as the Keypad.
The Alt key can be used, for instance, to switch between a decimal and a hexadecimal Keypad.
Key Operation
! Inputs a !.
" Inputs a ".
# Inputs a #.
$ Inputs a $.
% Inputs a %.
&. Inputs a &.
' Inputs a '.
( Inputs a (.
) Inputs a ).
* Inputs a *.
+ Inputs a +.
, Inputs a ,.
- Inputs a -.
. Inputs a .
/ Inputs a /.
0 to 9 Inputs a number from 0 to 9.
: Inputs a :.
; Inputs a ;.
< Inputs a <.
= Inputs a =.
