WindO/I-NV4 User’s Manual 26-11
3 Simulator
26
Simulator Function
3.3 Custom Monitor
Enables the values of registered device addresses to be monitored and changed.
■ Add to List
Saves device addresses registered in Monitor to project data as a device address list. A saved lists can be monitored
by selecting it from the List.
Click this button to display the Device Address List Name Setting dialog box. For details, refer to Chapter 25 “Saving
Registered Device Addresses to Project Data as a Device Address List” on page 25-11.
■ Device Address
Registers the device addresses to monitor individually.
Click this button to display the Tag Editor. For details, refer to Chapter 25 “Registering the device addresses to
monitor” on page 25-9.
■ Script
Batch saves all device addresses used in a script.
Click this button to display Script Manager. For details, refer to Chapter 25 “Batch Saving Device Addresses Used in
Scripts” on page 25-9.
■ Import
Imports the device addresses from a device address list saved as a CSV text file.
Click this button to display the Device Address List dialog box. For details, refer to Chapter 25 “Importing Device
Addresses from a Device Address List” on page 25-13.
■ Export
Saves the device addresses displayed in Monitor as a CSV text file. This file is called a Device Address List.
Click this button to display the Save As dialog box. For details, refer to Chapter 25 “Saving a Device Address List as a
CSV File” on page 25-12.
The saved device address list can be imported using Import.
■ Clear
Deletes all the device addresses displayed in Monitor.
■ List
Displays a device address list saved with the project data.
Select a list to clear the device addresses shown in Monitor and display the device addresses in the list.
Double-click a cell to display the Device Address List Name Setting dialog box. The name of the device address list can
be edited.
Select a list and press DELETE to delete it from the List.
To Next Page
