WindO/I-NV4 User’s Manual 25-11
1 Monitoring with WindO/I-NV4
25
Monitor Function
Saving Registered Device Addresses to Project Data as a Device Address List
If registered device addresses are saved with project data as a list, then even when the project data is later reopened,
the device addresses can be called from the List to be reutilized.
1 Click Add to List.
The Device Address List Name Setting dialog box is displayed.
2 Enter a name for the device address list.
The maximum number is 40 characters.
3 Click OK.
The device address list is added to the List.
4 Saving project data.
The following characters cannot be used for names of device address list.
" * , / : ; < > ? \ |
If a project file is closed without saving, device address lists will not be saved with the project data.
