1 Monitoring with WindO/I-NV4

25-12 WindO/I-NV4 User’s Manual

Saving a Device Address List as a CSV File

To use a device address list (registered device addresses list) in another project, save it as a CSV text file. This file is

called a Device Address List.

1 Click Export.

The Save As dialog box is displayed.

2 Select the save location, enter a File name, and then click Save.

This concludes saving device address list.
