5 Message Display
10-98 WindO/I-NV4 User’s Manual
5.2 Message Display Configuration Procedure
This section describes the configuration procedure for Message Displays.
1 On the Home tab, in the Parts group, click Data Displays, and then click Message Display.
2 Click a point on the edit screen where you wish to place the Message Display.
3 Double-click the placed Message Display and a Properties dialog box will be displayed.
4 Change the settings on each tab as necessary.
The Trigger Condition tab and Options tab only appear in Advanced mode.
You can set the default for the Message Display on the Default Preferences tab of the WindO/I-NV4
Options dialog box. For details, refer to Chapter 2 “Default Preferences Tab” on page 2-63.
To Next Page
