WindO/I-NV4 User’s Manual 17-11

4 Using the Data

Preventive Maintenance Function

4.1 Displaying the Counted Operation Count on a Numerical Display

1 On the Configuration tab, in the System Setup group, click Preventive Maintenance.

The Preventive Maintenance Settings dialog box is displayed.

2 Specify the number of device addresses to monitor in Number of Items.

3 Select the item to display in Settings with Display Options.

Select Operation Count.

Operation count settings are displayed in Settings.

4 Select the number to register the Preventive Maintenance settings to in Settings, then click Edit.

The Individual Settings dialog box is displayed.

5 Specify the bit device or the bit number of the word device to monitor with Monitor Device Address.
