4 HG2G-5T, HG1G

35-54 WindO/I-NV4 User’s Manual

4.1 Packing content

Before installing the HG2G-5T, HG1G, make sure that the specifications of the product conform to your requirements,

and that no parts are missing or damaged due to accidents during transportation.

4.2 Type No.

4 HG2G-5T, HG1G

Name HG2G-5T HG1G

HG2G-5T, HG1G Unit

Instruction Sheet

(Japanese/English/Simplified Chinese)

x 1 x 1

Mounting clips

Communication plug for external devices

(Attached to the HG2G-5T, HG1G)

USB Cable Lock Pin

USB Clamp Band

x 1

x 4

x 2

x 1 x 1

x 1 x 2

LCD size Bezel color Type No.

5.7 inch TFT Monochrome LCD

Light gray HG2G-5TN22TF-W

Dark gray HG2G-5TN22TF-B

Silver HG2G-5TN22TF-S

5.7 inch TFT Color LCD

Light gray HG2G-5TT22TF-W

Dark gray HG2G-5TT22TF-B

Silver HG2G-5TT22TF-S

4.3 inch TFT Color LCD

Black HG1G-4VT22TF-B

Silver HG1G-4VT22TF-S
