1 External Memory Devices
31-4 WindO/I-NV4 User’s Manual
1.5 Reading/Writing Data
● Using WindO/I-NV4 to read and write to an external memory device inserted in the MICRO/I
This procedure shows how to read and write data to the External Memory Device folder
*1
specified for the project
currently running on the MICRO/I.
Use either method below to make the connection.
• Connect a USB cable to the USB port on the computer and the USB interface on the MICRO/I.
*2
• Connect an Ethernet cable to the Ethernet port on the computer and the Ethernet interface on the MICRO/I.
Communication settings
Follow these procedures to configure the communication device and port to allow reading and writing to the external
memory device inserted in the MICRO/I.
1 On the Home tab, in the Project group, click Comm. Setup.
The Communication Settings dialog box appears.
2 Select Operator Interface under Communicate with.
3 Select the type of connection under Port, then click OK.
*1 USB flash drive inserted in USB1 for HG2J-7U, SD memory card for HG5G/4G/3G/2G-V, HG4G/3G and HG2G-5F,
USB flash drive for HG2G-5T and HG1G/1P
*2 HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F/-5T, HG1G/1P only
External Memory Device
MICRO/I
USB flash drive
SD memory card
Computer
USB Cable
Ethernet Cable
To USB Port To USB Interface
Mini-B PlugA Plug
To Ethernet Port To Ethernet Interface
To Next Page
