9 Potentiometer
8-164 WindO/I-NV4 User’s Manual
9.2 Potentiometer Configuration Procedure
This section describes the configuration procedure for Potentiometer parts.
1 On the Home tab, in the Parts group, click Buttons, and then click Potentiometer.
2 Click a point on the edit screen where you wish to place the Potentiometer.
3 Double-click the placed Potentiometer and a Properties dialog box will be displayed.
4 Change the settings on each tab as necessary.
The Trigger Condition tab and Options tab only appear in Advanced mode.
You can set the default for the Potentiometer on the Default Preferences tab of the WindO/I-NV4
Options dialog box. For details, refer to Chapter 2 “Default Preferences Tab” on page 2-63.
