3 Global Script
20-16 WindO/I-NV4 User’s Manual
A Global Script operates for the entire project. The scripts are executed in order on the list and in accordance with the trigger
conditions after the parts on the MICRO/I screen are processed. A maximum of 16 Global Scripts can be set to a project.
3.1 Setting procedures for Global Script
Global Script is setup using the following procedures.
1 On the Configuration tab, in the System Setup group, click Global Script.
The Global Script Settings dialog box is displayed.
2 Under Settings, select the script ID to configure, and then click Edit.
The Global Script dialog box is displayed.
3 On the General tab, select the Use Global Script check box.
3 Global Script
HG3G HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T HG4G HG1G HG1P HG2J-7U
With Global Script, you cannot do indirect read and indirect write of the external device address.
For details about the indirect read and indirect write, refer to Chapter 2 “Indirect Read and Indirect Write
Settings” on page 2-5.
