● Indirect Read and Indirect Write Settings
The indirect specification of a device address means to add a value (indirect value) to the address number of the set
device address and use that address number as the actual read source or write destination. You can change the read
source or write destination address number just by changing this indirect value.
Indirect read
Add the indirect value to the address number of the device address set as the read source and read the value of the
indirectly specified device address.
Example: To read an indirectly specified value of device address into LDR200
When the device set as the read source is LDR10 and the indirect value’s device address is D21, if 4
(indirect value: 4) is set in D21, the device address of the value actually read is LDR14.
Indirect write
Add the indirect value to the address number of the device address set as the write destination and write a value to
the indirectly specified device address.
Example: To write the value in LDR20 to an indirectly specified device address
When the device set as the write destination is LDR100 and the indirect value’s device address is D20, if 3
(indirect value: 3) is set in D20, the device address of the value actually written is LDR103.
Parts you can indirectly read and indirectly write
Device address set as read source
Device address with actually read value
Device address for Indirect value
200LDR11
300LDR12
100LDR10
500LDR14
4D21
500LDR200
4 words
Indirect value
Read
LDR13 400
200LDR101
300LDR102
100LDR100
1000LDR103
3D20
1000LDR20
3 words
Indirect value
Device address set as write source
Device address with actually written value
Device address for Indirect value
Write
Part Indirect read Indirect write
Word Button YES YES
Multi-Button YES YES
Numerical Input YES YES
Character Input YES YES
Numerical Display YES NO
Word Write Command YES YES
Script Command YES YES
Multi-Command YES YES
• Enter the value for indirect values as the data type UBIN16(W). Indirect values can be set in the range of
0 to 32767. When an indirect write is executed with an out-of-range indirect value, “Device range error”
is displayed. Similarly, when an indirect read is executed, the previous value before the indirect value
changed is retained for a data display part, and “Device range error” is displayed for a part that is not a
data display part.
• For reading device address indirectly, decide the read source address number after the indirect value changes
and after the screen changes, and then read the value of device address. For the device address of an
external device, communication may take some time as the value is read from the external device, so when
transferring or calculating the data that was read, repeatedly execute the corresponding part.
