2 Downloading
24-18 WindO/I-NV4 User’s Manual
2.3 Downloading Files to an External Memory Device Inserted in the MICRO/I
Specified files can be downloaded to an external memory device
*1
inserted in the MICRO/I. The files are downloaded
to External Memory Device folder specified in the Project Settings dialog box for the current project.
1 Insert the external memory device into the MICRO/I.
2 Change communication settings according to the connection method between the computer and the MICRO/I.
In the Communication Settings dialog box, select Operator Interface from Communicate with. For details,
refer to “1.3 Change Communication Settings” on page 24-5.
3 On the Home tab, in the Project group, click the arrow under Download.
4 Select the method for downloading the file to the external memory device.
The Open dialog box is displayed.
■ Files to External Memory Device
Stops operation of the MICRO/I and downloads the file to the external memory device inserted in the MICRO/I. When
the file download is complete, operation resumes.
■ Files to External Memory Device while running
Downloads the file to the external memory device inserted in the MICRO/I without stopping operation of the MICRO/I.
*1 USB flash drive inserted in USB1 for HG2J-7U, SD memory card for HG5G/4G/3G/2G-V, HG4G/3G and HG2G-5F,
USB flash drive for HG2G-5T and HG1G/1P
HG3G
HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T
HG4G HG1G HG1P
HG2J-7U
MICRO/I
External memory device
USB flash drive
SD memory card
While editing project data, even if you click the arrow under Download in the Transfer group on the
Online tab, the download menu will be displayed.
