7 BACnet Communication
3-104 WindO/I-NV4 User’s Manual
7.5 BACnet/IP Operation
BACnet/IP is enabled and disabled according to the value of HMI Special Internal Relay LSM70 (BACnet
Communication Bit).
Properties with allocated device addresses work by referencing those device addresses.
When BACnet/IP is enabled and properties or the values of device addresses that are associated with properties are
changed, they operate with the values after the change.
BACnet/IP
Properties with Allocated Device Addresses
and the Values of Those Device Addresses
Enabled Bound
Disabled Not bound
When the status of the BACnet communication is stopped by error (the value of HMI Special Data Registers
LSD260-3 is 1) and restarts the BACnet communication, set 0 to the value of HMI Special Internal Relay
LSM70, and then set 1 to the value of HMI Special Internal Relay LSM70 after the status of the BACnet
communication is stopped (the value of HMI Special Data Registers LSD260-0 is 1).
