WindO/I-NV4 User’s Manual 10-155
8 Alarm Log Display
10
Data Displays
8.3 Properties of Alarm Log Display Dialog Box
This section describes items and buttons on the properties dialog box.
●
General Tab
■ Part Name
Enter a name for the part. The maximum number is 20 characters.
■ Alarm Log Settings
Displays the Alarm Log Settings dialog box.
■ Default Settings
These options configure the default settings when the Alarm Log Display is displayed.
Start Line Number: Specifies what number alarm to display when multiple alarms have occurred.
The range that can be specified varies based on the model type.
HG2J-7U, HG2G-5T, HG1G/1P: 1 to 5520
HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F: 1 to 11660
Sort: Selects the display order for alarms that have occurred from the following.
Old, New, New & Level
Focus: Selects a style of the focus from the following.
Reverse Performs the negative/positive conversion to the entire row that has the focus.
Occurrence Message Recovered Confirmed
12/01 12 : 00 Current fault
12/01 12 : 00 Current fault 12 : 50
12/01 12 : 00 Current fault 12 : 54
Occurrence Message Recovered Confirmed
12/01 12 : 00 Current fault
12/01 12 : 00 Current fault 12 : 50
12/01 12 : 00 Current fault 12 : 54
Up Down CheckSelect Delete Up Down CheckSelect Delete
To Next Page
