2 Operation Log Function Configuration Procedure
15-8 WindO/I-NV4 User’s Manual
This section describes the configuration procedure for the Operation Log function.
2.1 Configuring the Events and the Condition for Recording
1 On the Configuration tab, in the System Setup group, click Operation Log.
The Operation Log Settings dialog box is displayed.
2 Select the Enable Operation Log Settings check box.
3 Select the check boxes for the events to record under Target Events to record.
2 Operation Log Function Configuration Procedure
HG3G
HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T
HG4G HG1G HG1P
HG2J-7U
Power ON: The following items are recorded when the MICRO/I power is turned on.
Time, Screen Number, Event Name
Switch to Base Screen: The following items are recorded when the base screen is switched.
Time, User Name, Screen Number, Event Name, Changed to
Change Users: The following items are recorded when the user is changed.
Time, User Name, Screen Number, Event Name, Changed to
Change Operation Modes: The following items are recorded when the operation mode is changed.
Time, User Name, Screen Number, Event Name, Changed to
Press buttons: The following items are recorded when a touch switch is pressed.
Time, User Name, Screen Number, Event Name, Part Name
Write Data to any Device Addresses: The following items are recorded when a value is written to a device address
by pressing a touch switch.
Time, User Name, Screen Number, Event Name, Device Address, Changed to
To Next Page
