WindO/I-NV4 User’s Manual 25-27
2 Monitoring on the MICRO/I
25
Monitor Function
2.3 Change Values of Device Addresses and Check the Operation of Project Data Offline
Offline mode allows you to change values of device addresses and to check the operation of project data on the
MICRO/I unit only. By possessing virtualized external device addresses inside the MICRO/I, you can efficiently debug
using the Device Monitor function.
●
Switching to Offline Mode
1 Press the upper-left corner of the screen on the MICRO/I for three seconds or more.
The Maintenance Screen is displayed.
2 Press System Mode.
The MICRO/I switches to the Top Page of the System Mode.
3 Press Offline.
The MICRO/I switches to offline mode and “Offline Mode” is displayed at the bottom left of the screen.
4 Monitor and change the values of device addresses with Device Monitor to check the operation of project data.
If there are any errors, edit the project data with WindO/I-NV4, and then download the edited project data to the
MICRO/I.
To exit offline mode, switch to System Mode with the operations in steps
1 and 2, and then press Run on the Top
Page.
Press and hold 3
or more seconds
MICRO/I
Maintenance
System Mode
Device Monitor
Adjust Brightness
If a password has been configured for the project data, the Enter Password screen will be displayed. Select
a user name and then enter a password. For details, refer to Chapter 23 “User Accounts and the Security
Function” on page 23-1.
Run Offline Main Menu
<< >>
BRIGHTNESS 31
MAC Address 00:03:7B:F0:12:A8
IP Address 192.168.0.1(DHCP)
2010/OCT/14/THU 14:56:44
IDEC HG G SERIES
SYSTEM MODE TOP PAGE
ENG/JPN
To Next Page
