WindO/I-NV4 User’s Manual 2-61

4 Customizing WindO/I-NV4

WindO/I-NV4 Features & Basic Operations

4.1 Configuring the Work Environment

You can configure WindO/I-NV4 settings such as mode and options when editing screens, the path when selecting

files, and the path for automatic backups. The settings configured here are saved even when you exit WindO/I-NV4.

The procedure for configuring the work environment is shown below.

1 Click and then click WindO/I-NV4 Options.

The WindO/I-NV4 Options dialog box is displayed.

2 Change the settings on each tab as desired.
