WindO/I-NV4 User’s Manual 10-173
9 Data Log Display
10
Data Displays
9.3 Properties of Data Log Display Dialog Box
This section describes items and buttons on the properties dialog box.
●
General Tab
■ Part Name
Enter a name for the part. The maximum number is 20 characters.
■ Display data from specified date
When stopping updating the display, to display the data from the Start
Date, select this check box and specify the bit device or the bit number of the word device to control the display.
Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device
Address Settings” on page 2-70.
Displays from the data of Start Date when the value of device address changes from 0 to 1.
Start Date and Time: Specifies the Start Date for the display data as the values of word devices.
Click to display the Tag Editor. For the device address configuration procedure, refer to
Chapter 2 “5.1 Device Address Settings” on page 2-70.
For address number assignment, refer to Chapter 11 “Specifying Date and Time with Values
of device addresses” on page 11-33.
This option can only be configured when Display data from specified date check box is
selected.
To Next Page
