3 DM Link Communication
3-6 WindO/I-NV4 User’s Manual
3.2 DM Link Communication Settings
DM Link Communication settings are selected on the Select Communication Driver dialog box, or the
Communication Driver tab on the Project Settings dialog box.
• By clicking , and then clicking New, following displayed dialog boxes and configuring settings, the Select
Communication Driver dialog box is displayed. For details, refer to Chapter 4 “Create new project data by using the
interactive quick start” on page 4-1.
• Click Communication Driver on the status bar to display the Communication Driver tab on the Project
Settings dialog box. For details, refer to Chapter 4 “Changing Communication Drivers” on page 4-21.
Select IDEC System in Manufacturer, and then select DM Link (1:1), DM Link (1:N) or DM Link Ethernet
(UDP)
*1
in Communication Driver.
*1 HG2J-7U, HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F only
To Next Page
