3 Part Types
6
Drawings and Parts
This section describes the parts that can be used on the MICRO/I.
3.1 Buttons
3.2 Lamps
3.3 Data Displays
*1 HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F/-5T, HG1G/1P only
*2 This is applicable for models with a video interface only.
3 Part Types
HG3G
HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T
HG4G HG1G HG1P
HG2J-7U
Part Description
Bit Button Writes a 0 or 1 to a bit device.
Word Button
Writes a value to a word device. Can be used to indirectly specify the destination address
number or to perform operations on the written value.
Goto Screen Button Switches to another screen or displays a window.
Print Button Outputs a screenshot to a printer or external memory devices.
Key Button
Performs a variety of functions including uploading and downloading, copying files, and
operating other parts.
Multi-Button Executes multiple commands at once.
Keypad
A part comprised of Key Buttons. Enters numbers and characters into numerical or character
input parts.
Selector Switch
*1
Writes a 0 or 1 to a bit device. This is an exclusive control that only writes a single value as
1 and all other values as 0.
Potentiometer
*1
Writes a value selected by pressing a slider button to a word device.
Part Description
Pilot Lamp Displays images. Switches the displayed image according to the value of a bit device.
Multi-State Lamp Displays images. Switches the displayed image according to the value of a word device.
Part Description
Numerical Input Uses either a Keypad or Key Button to write entered numbers.
Character Input Uses either a Keypad or Key Button to write the character code for entered characters.
Picture Display
Displays images. Switches, moves or enlarges/reduces the displayed image according to the
value of a device address, the bit status within a word device or at a fixed period.
Video Display
*2
Displays images and plays movie files.
Message Display
Loads fixed text strings and word device values as character codes and displays them on the
screen.
Message Switching Display
Switches the displayed fixed text string according to the value of a word device or the bit
status within a word device.
Alarm List Display
Switches the displayed fixed text string according to the value of a device address. Can
display alarms and multiple fixed text strings.
Alarm Log Display Displays the alarm log stored in the internal memory of the MICRO/I.
Data Log Display
Displays the data log stored in the internal memory of the MICRO/I or the external memory
device.
Numerical Display Displays the numerical in the specified format.
Calendar Displays the date and time using the MICRO/I's calendar data.
