2.1 Downloading Project Data to the MICRO/I
1 Change communication settings according to the connection method between the computer and the MICRO/I.
In the Communication Settings dialog box, select Operator Interface from Communicate with. For details,
refer to “1.3 Change Communication Settings” on page 24-5.
For the HG2J-7U, select the check box of the target in (Target list).
2 Open a project to download.
3 On the Home tab, in the Project group, click the Download icon.
The Download dialog box is displayed.
For the HG2J-7U, proceed to step
5.
2 Downloading
HG3G
HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T
HG4G HG1G HG1P
HG2J-7U
(Target list)
To download a project without opening it, on the Home tab, in the Project group, click the Download
icon. The Open dialog box is displayed. Select a file then click Open. The Download dialog box is displayed.
Proceed to Step
4.
When project data is downloaded to the MICRO/I, the MICRO/I screen data is overwritten.
If the project data was changed, a confirmation message to save the project data is displayed.
• Click OK to save the project data and display the Download dialog box.
• Click Cancel to return to the editing screen without saving the project data.
