4 Drawings and Parts Overlapping
6-10 WindO/I-NV4 User’s Manual
4.3 Restrictions
• To place overlapping drawings and parts on a screen, we recommend they be placed on the top layer. If the
number of objects placed on the top layer exceeds the limit, only the objects that exceed the limit will be placed on
the base screen or popup screen. At this time, the value of HMI Special Internal Relay LSM33 is 1. For details, refer
to Chapter 33 “HMI Special Relay (LSM)” on page 33-2.
• When the Message Display, Message Switching Display, and Alarm List Display have their Scroll check box selected
on the Format tab in the Properties dialog box and they are placed on the top layer, the scrolling speed of the
text will be slower.
• On the Top Layer, magenta (R:255, G:4, B:255) is treated as the transparent color. If you place pictures used this
color on a Top Layer, those areas are completely transparent.
• When the following objects are placed on the Top Layer, the text is displayed with a color mixed with magenta. If
the text color causes a problem, set the Background Color of the text or change it to Windows font.
- Texts with Background Color set to None
- Parts with Image Type set to None
- Parts for which Not Display Image is selected
- Parts using the pictures with the background of the texts replaced with a Transparent Color.
