10 Numerical Display
10-186 WindO/I-NV4 User’s Manual
10.2 Numerical Display Configuration Procedure
This section describes the configuration procedure for Numerical Displays.
1 On the Home tab, in the Parts group, click Data Displays, and then click Numerical Display.
2 Click a point on the edit screen where you wish to place the Numerical Display.
3 Double-click the placed Numerical Display and a Properties dialog box will be displayed.
4 Change the settings on each tab as necessary.
The Data Over tab, Trigger Condition tab and Options tab only appear in Advanced mode.
You can set the default for the Numerical Display on the Default Preferences tab of the WindO/I-NV4
Options dialog box. For details, refer to Chapter 2 “Default Preferences Tab” on page 2-63.
To Next Page
