6 Multi-Button
8-112 WindO/I-NV4 User’s Manual
6.2 Multi-Button Configuration Procedure
This section describes the configuration procedure for Multi-Buttons.
1 On the Home tab, in the Parts group, click Buttons, and then click Multi-Button.
2 Click a point on the edit screen where you wish to place the Multi-Button.
3 Double-click the placed Multi-Button and a Properties dialog box will be displayed.
4 Change the settings on each tab as necessary.
The Trigger Condition tab and Options tab only appear in Advanced mode.
You can set the default for the Multi-Button on the Default Preferences tab of the WindO/I-NV4
Options dialog box. For details, refer to Chapter 2 “Default Preferences Tab” on page 2-63.
To Next Page
