WindO/I-NV4 User’s Manual 8-111

6 Multi-Button

8

Buttons

■ Momentary

■ Alternate

The button turns ON when pressed,

and OFF when released.

Release

Initial image

Press ReleasePress

ON

Operation and

view

Action

ONOFF OFF

The button switches between ON and

OFF each time it is pressed.

Release

Initial image

Press ReleasePress

ON

Operation and

view

Action

OFF
