3 Goto Screen Button
8-40 WindO/I-NV4 User’s Manual
3.2 Goto Screen Button Configuration Procedure
This section describes the configuration procedure for Goto Screen Buttons.
1 On the Home tab, in the Parts group, click Buttons, and then click Goto Screen Button.
2 Click a point on the edit screen where you wish to place the Goto Screen Button.
3 Double-click the placed Goto Screen Button and a Properties dialog box will be displayed.
4 Change the settings on each tab as necessary.
The Trigger Condition tab and Options tab only appear in Advanced mode.
You can set the default for the Goto Screen Button on the Default Preferences tab of the WindO/I-NV4
Options dialog box. For details, refer to Chapter 2 “Default Preferences Tab” on page 2-63.
To Next Page
