WindO/I-NV4 User’s Manual 5-31
6 Screen Restrictions
5
Screen
6.3 Maximum Number of External Device Addresses
The maximum number of Read/Write device addresses of external devices is 512 for base screens (including overlay
screens) and popup screens.
6.4 Text and Messages
Follow the rules below, otherwise text and messages on the MICRO/I may not be displayed or may be partially
missing.
6.5 Vertical Installation
Even if you choose for them to be installed and displayed vertically, the screens in the System Mode will be the same
as horizontal installation and display.
If the same device address is used in multiple device address settings, the used number of device addresses
will be counted as 1 device address. It will not be counted as 1 point per device address setting.
Popup screen title, Password Input Screen title: Make shorter than the title bar
Text on drawings: Make smaller than the text area
Text and messages used in parts: Make smaller than the size of the parts
