WindO/I-NV4 User’s Manual 8-147
8 Selector Switch
8
Buttons
8.2 Selector Switch Configuration Procedure
This section describes the configuration procedure for Selector Switch buttons.
1 On the Home tab, in the Parts group, click Buttons, and then click Selector Switch.
2 Click a point on the edit screen where you wish to place the Selector Switch.
3 Double-click the placed Selector Switch and a Properties dialog box will be displayed.
4 Change the settings on each tab as necessary.
The Trigger Condition tab and Options tab only appear in Advanced mode.
You can set the default for the Selector Switch on the Default Preferences tab of the WindO/I-NV4
Options dialog box. For details, refer to Chapter 2 “Default Preferences Tab” on page 2-63.
