4 Meter

11-64 WindO/I-NV4 User’s Manual

4.1 How the Meter is Used

The meter displays the value of a word device as the movement of a needle.

• Display the value of a word device in a meter

4 Meter

HG3G

HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T

HG4G HG1G HG1P

HG2J-7U

External device

MICRO/I

D100 :

0 100

20 80

40 60

0 100

20 80

40 60
