WindO/I-NV4 User’s Manual 8-165
9 Potentiometer
8
Buttons
9.3 Properties of Potentiometer Dialog Box
This section describes items and buttons in the Properties dialog box.
●
General Tab
■ Part Name
Enter a name for the part. The maximum number is 20 characters.
■ Data Type
Select the data type to be handled by the Potentiometer.
For details, refer to Chapter 2 “1.1 Available Data” on page 2-1.
■ Minimum
Specify the minimum value that can be entered. The minimum value differs depending on the data type.
■ Maximum
Specify the maximum value that can be entered. The maximum value differs depending on the data type.
■ Destination Device Address
Specify the destination word device.
Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device
Address Settings” on page 2-70.
To Next Page
