5 Part Library Function
6-12 WindO/I-NV4 User’s Manual
5.2 How to use the Library Part in a project
1 Double click the category folder that contains the library part you want to use.
Images of library parts are displayed on the library screen.
2 Select the library part and drag and drop it on the editing screen.
Drag and drop
Part Library
Library Screen
If the library part is placed on the editing screen and the corresponding project does not recognize the
device address, the device address setting associated with the part becomes blank.
Example: When a bit button (Destination Device Address: #M0), registered as a library part and is created
by using the HG5G-V project, is placed on the HG2J-7U project, the Destination Device Address
becomes blank.
To Next Page
