2 FTP Server Function
28-16 WindO/I-NV4 User’s Manual
2.1 What Can Be Done with the FTP Server Function
The FTP server function enables communication from MICRO/I (FTP server) to a computer (FTP client). From the FTP
client, the followings are enabled.
• Reading files from the external memory device inserted in the MICRO/I
• Writing files to the external memory device inserted in the MICRO/I
2.2 System Composition
An example system configuration for using the FTP server function is shown below.
Configure the MICRO/I Ethernet settings (IP address, subnet mask, default gateway) and connect to a local network.
*1 Only USB flash drive for HG2J-7U, HG2G-5T and HG1G/1P
2 FTP Server Function
HG3G
HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T
HG4G HG1G HG1P
HG2J-7U
(1) Access the MICRO/I from a FTP client connected to the local network to use the FTP server function, and read or
write the file contained in the external memory device inserted in the MICRO/I.
(2) When the local network is connected to an external network, configure the FTP client connected to the remote
network with the local network’s gateway, router, and other settings. Access the MICRO/I from the remote FTP
client to read or write the files contained in the external memory device inserted in the MICRO/I.
FTP Server
FTP Client
(Computer)
FTP Client
(Computer)
Local Network Ethernet Communication (TCP/IP)
Remote Network
(1)
(2)
External device
MICRO/I
USB flash drive
SD memory card
File File
External Network
External Memory Device
*1
For gateway, router, and other settings, contact the administrator of the network which the MICRO/I is
connected to.
