7 BACnet Communication
3-94 WindO/I-NV4 User’s Manual
7.1 Overview
BACnet communication stands for "Building Automation and Control Networking Protocol". In building equipment, it is
an open protocol that has been standardized for interoperability between systems built by different manufacturers,
and a communication standard for building networks.
Previous air conditioning, lighting, security, and fire protection systems were connected using methods unique to the
building equipment and systems manufacturers. However, conforming to BACnet allows equipment and systems to be
connected and monitored using a common method.
A device connected by BACnet, and a device compatible with BACnet/IP is called a BACnet device.
7 BACnet Communication
HG3G
HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T
HG4G HG1G HG1P
HG2J-7U
BACnet
Lighting
equipment
Mfgr. B
HVAC
equipment
Mfgr. A
Security
equipment
Mfgr. C
Fire protection
equipment
Mfgr. D
Administration server
BACnet Devices
