WindO/I-NV4 User’s Manual 10-81

4 Video Display

Data Displays

This function is only supported by models that are equipped with a video interface.

4.1 How the Video Display is Used

• Play movie files

• Display video camera images on the MICRO/I and output microphone audio

from a connected speaker

• Display images of two video cameras on the MICRO/I

*1 HG5G/4G/3G-V only

*2 This is applicable for HG4G/3G with a video interface only.

*3 Recording sound function is for HG4G/3G only

4 Video Display

HG3G

HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T

HG4G HG1G HG1P

HG2J-7U

MICRO/I

Play

Play Stop Back Next

SD memory card

Movie Files

(AVI format)

(MP4 format)

Movie File List

(MOVIE.LST)

HG4G HG3G

HG5G-V HG4G-V HG3G-V

Video Camera

Microphone

Images

Audio

MICRO/I

Play Stop Back Next

HG4G HG3G

HG5G-V HG4G-V HG3G-V

Video Camera

Images

Channel 1

Audio

Channel 2

MICRO/I

HG5G-V HG4G-V HG3G-V

再生停止前へ次へ

CH1

再生停止前へ次へ

CH2
