5 Key Button
8-74 WindO/I-NV4 User’s Manual
5.2 Key Button Configuration Procedure
This section describes the configuration procedure for Key Buttons.
1 On the Home tab, in the Parts group, click Buttons, and then click Key Button.
2 Click a point on the edit screen where you wish to place the Key Button.
3 Double-click the placed Key Button and a Properties dialog box will be displayed.
4 Change the settings on each tab as necessary.
The Trigger Condition tab and Options tab only appear in Advanced mode.
You can set the default for the Key Button on the Default Preferences tab of the WindO/I-NV4 Options
dialog box. For details, refer to Chapter 2 “Default Preferences Tab” on page 2-63.
