2 Line Chart
11
Charts
Specifying Date and Time with Values of device addresses
Using this option requires the sequential address number of 6 words starting from the specified device address. The
data is handled as BCD4(B) values in the order of year, month, day, hour, minute, and second.
Example: Top Device Address is LDR100, and the date and time is October 1 2018 12:01:30.
■ Scale
Read source Date and time data
(the address number of Top Device Address) LDR 100 2018 (Year)
+1 LDR 101 10 (Month)
+2 LDR 102 1 (Day)
+3 LDR 103 12 (Hour)
+4 LDR 104 1 (Minute)
+5 LDR 105 30 (Second)
Show Ticks: Select this check box to display a scale on a X-axis.
Major Divisions: Enter the number of major scale divisions (1 to 20).
Minor Divisions: Enter the number of minor scale divisions (1 to 20).
Color: Selects the color of scales (color: 256 colors, monochrome: 16 shades).
Click Color to display the Color Palette. Select a color from the Color
Palette.
If the area for displaying the scale is small, the scale will not be displayed properly.
