WindO/I-NV4 User’s Manual 20-17
3 Global Script
20
Script
4 Specify the script ID (1 to 32,000) of the script to execute.
The Script Manager is displayed when the button is clicked. The script can be selected from the script list of the
Script Manager. For details, refer to “2.2 Script Manager” on page 20-7.
5 Click Trigger Condition tab.
6 With Trigger Type, select the condition to execute the script.
■ Rising-edge
Script is executed when trigger device address changes from 0 to 1. Specify the bit device or the bit number of the
word device for Device Address.
Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device
Address Settings” on page 2-70.
■ Falling-edge
Script is executed when trigger device address changes from 1 to 0. Specify the bit device or the bit number of the
word device for Device Address.
Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device
Address Settings” on page 2-70.
■ Always Enabled
The script is executed on every scan of the MICRO/I.
■ Fixed Period
Script is executed at set intervals. Specify Period in seconds.
7 Click OK to close the Global Script dialog box.
8 Click Close on the Global Script Settings dialog box.
This concludes the Global Script configuration.
