WindO/I-NV4 User’s Manual 30-3
1 Overview
30
Expansion Modules
■ Digital Combination I/O Modules
●
Analog I/O Module
IDEC MicroSmart PLC Analog I/O modules that can be attached as expansion modules are shown below.
■ Analog Input Module
■ Analog Output Module
■ Mixed Analog I/O Module
Type Model No. Terminal
Dimensions
(L x W x H (mm))
Consumption
Current (mA)
HG5G/
4G/3G/
2G-V
HG4G
/3G
HG2G
-5F
5 V 24 V
4 points/DC Input,
4 points/Relay Output
FC4A-M08BR1
Removable Screw
terminal block
90.0×23.5×70.0 25 20 NO YES YES
16 points/DC Input,
8 points/Relay Output
FC4A-M24BR2
Non-removable
Terminal Block
90.0×39.1×70.0 65 45 NO YES YES
4 points/DC Input,
4 points/Relay Output
FC6A-M08BR1
Removable Screw
terminal block
90.0×23.6×73.0 30 25 YES YES YES
16 points/DC Input,
8 points/Relay Output
FC6A-M24BR1 90.0×39.2×73.0 55 50 YES YES YES
4 points/DC Input,
4 points/Relay Output
FC6A-M08BR4
Removable
Push-in terminal
block
90.0×23.6×73.0 30 25 YES YES YES
16 points/DC Input,
8 points/Relay Output
FC6A-M24BR4 90.0×39.2×73.0 55 50 YES YES YES
HG3G
HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T
HG4G HG1G HG1P
HG2J-7U
Type Model No.
Input Type
Voltage Current Thermocouple
Resistance
Thermometer
Thermistor
2 points Input
FC6A-J2C1
FC6A-J2C4
0 to 10 V/
-10 to +10 V
0 to 20 mA/
4 to 20 mA
― ― ―
4 points Input
FC6A-J4A1
FC6A-J4A4
0 to 10 V/
-10 to +10 V
0 to 20 mA/
4 to 20 mA
― ― ―
8 points Input
FC6A-J8A1
FC6A-J8A4
0 to 10 V/
-10 to +10 V
0 to 20 mA/
4 to 20 mA
― ― ―
4 points Input
FC6A-J4CN1
FC6A-J4CN4
0 to 10 V/
-10 to +10 V
0 to 20 mA/
4 to 20 mA
K/ J/ R/ S/ B/ E/
T/ N/ C
Pt100/Pt1000/
Ni100/Ni1000
―
4 points Input
FC6A-J4CH1Y
FC6A-J4CH4Y
― ―
K/ J/ R/ S/ B/ E/
T/ N/ C
― ―
8 points Input
FC6A-J8CU1
FC6A-J8CU4
― ―
K/ J/ R/ S/ B/ E/
T/ N/ C
― NTC/PTC
Type Model No.
Output Type
Voltage Current
2 points Output
FC6A-K2A1
FC6A-K2A4
0 to 10V/-10 to +10V 0 to 20mA/4 to 20mA
4 points Output
FC6A-K4A1
FC6A-K4A4
0 to 10 V/-10 to +10 V 0 to 20 mA/4 to 20 mA
Type Model No.
Input Type Output Type
Voltage Current
Thermocouple
Resistance
Thermometer
Voltage Current
4 points Input,
2 points Output
FC6A-L06A1
FC6A-L06A4
0 to 10 V/
-10 to +10 V
0 to 20 mA/
4 to 20 mA
― ― ― ―
― ― ― ―
0 to 10 V/
-10 to +10 V
0 to 20 mA/
4 to 20 mA
2 points Input,
1 points Output
FC6A-L03CN1
FC6A-L03CN4
0 to 10 V/
-10 to +10 V
0 to 20 mA/
4 to 20 mA
K/ J/ R/ S/ B/
E/ T/ N/ C
Pt100/Pt1000/
Ni100/Ni1000
― ―
― ― ― ―
0 to 10 V/
-10 to +10 V
0 to 20 mA/
4 to 20 mA
To Next Page
