1 Overview
30-4 WindO/I-NV4 User’s Manual
Checking the Hardware Version Number
The analog I/O module hardware version number is printed on the side of the analog I/O module. The performance
and functionality of the analog I/O module will differ by its version, so check the version number before use.
●
Restrictions when connecting the expansion modules
• The expansion module for FC6A and the expansion module for FC4A cannot be used together.
• Always turn the MICRO/I and the expansion module off before attaching or detaching an expansion module.
• Use the expansion module clamp (sold separately) when using expansion modules.
Order the module clamp by referring to the width of the module shown in the dimensions of each module.
• When connecting more than 2 expansion modules, note the limits shown below.
S/N:XXXXX-XXXXX V100
Version Number
Type No.
Quantity of
Applicable Analog
I/O Modules
Total width when
connecting more
than 2 expansion
modules
Current flow rate
at 5V
Current flow rate
at 24V
HG5G-V 4 93.0 mm max. 130 mA max. 50 mA max.
HG4G/3G-V, HG4G/3G 4 93.0 mm max. 130 mA max. 150 mA max.
HG2G-V, HG2G-5F 2 70.0 mm max. 130 mA max. 150 mA max.
HG3G
HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T
HG4G HG1G HG1P
HG2J-7U
To Next Page
