WindO/I-NV4 User’s Manual 30-5
1 Overview
30
Expansion Modules
● Expansion Module Slot Information
Expansion module type information is written to HMI Special Data Registers (LSD270 to 277). The details are shown below.
■ Status
■ Type ID
■ System Software Version
Displays the version of the system software written to the device.
HG3G HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T HG4G HG1G HG1P HG2J-7U
The model number, type, and system software version of the expansion modules installed in MICRO/I can
be checked on the Expansion Module Information dialog box. For details, refer to Chapter 24 “Expansion
Module Information Dialog Box” on page 24-33.
Upper Lower Description
LSD270 LSD271 Expansion Module Slot 1 Information
LSD272 LSD273 Expansion Module Slot 2 Information
LSD274 LSD275 Expansion Module Slot 3 Information
LSD276 LSD277 Expansion Module Slot 4 Information
Status Type ID Upper
Position Information System Software Version Lower
Slot Number (1 to 4)
Bit
15
Bit
0
Bit
7
Bit
8
12 34 5 6 910 1112 13 14
Status
Description
Hexadecimal Binary
0x00 0000 0000 Normal
0x81 1000 0001
Communication error (An error has occurred in the communication between MICRO/I
and an expansion module.)
0x82 1000 0010 Unknown device detected
0x83 1000 0011
Device setting error (No device is connected or the connected device is different from
the setting of the project.)
0x84 1000 0100 Device writing error (Failed to set the operation of the device.)
Type ID
Type No.
Hexadecimal Binary
0x00 0000 0000 FC6A-N16B1, FC6A-N16B4, FC6A-N16B3
0x01 0000 0001
FC6A-R161, FC6A-R164, FC6A-T16K1, FC6A-T16K4, FC6A-T16P1, FC6A-T16P4,
FC6A-T16K3, FC6A-T16P3
0x02 0000 0010 FC6A-N32B3
0x03 0000 0011 FC6A-T32K3, FC6A-T32P3
0x04 0000 0100 FC6A-N08B1, FC6A-N08B4, FC6A-N08A11, FC6A-N08A14
0x05 0000 0101 FC6A-R081, FC6A-R084, FC6A-T08K1, FC6A-T08K4, FC6A-T08P1, FC6A-T08P4
0x06 0000 0110 FC6A-M08BR1, FC6A-M08BR4
0x07 0000 0111 FC6A-M24BR1, FC6A-M24BR4
0x20 0010 0000 FC6A-J2C1, FC6A-J2C4
0x21 0010 0001 FC6A-J4A1, FC6A-J4A4
0x22 0010 0010 FC6A-J8A1, FC6A-J8A4
0x23 0010 0011 FC6A-K2A1, FC6A-K2A4
0x24 0010 0100 FC6A-K4A1, FC6A-K4A4
0x25 0010 0101 FC6A-L06A1, FC6A-L06A4
0x26 0010 0110 FC6A-L03CN1, FC6A-L03CN4
0x27 0010 0111 FC6A-J4CN1, FC6A-J4CN4
0x28 0010 1000 FC6A-J8CU1, FC6A-J8CU4
0x2B 0010 1011 FC6A-J4CH1Y, FC6A-J4CH4Y
0xFF 1111 1111 Disconnect
