1 Communicating with the MICRO/I

24-10 WindO/I-NV4 User’s Manual

To execute a function other than the project data download

The Target IP Address dialog box will be displayed when any of the following functions are executed.

• Upload a project data.

• Upload data from an external memory device inserted in the MICRO/I.

• Delete data stored in the internal memory.

• Delete data from or formatting an external memory device inserted in the MICRO/I.

• Display information about system software and project data.

• Monitor the MICRO/I.

The dialog box allows you to specify the IP address of the target MICRO/I.

■ Target IP Address

Specify the IP address for the target MICRO/I to execute this function.

Click to display the Target List dialog box. Specify the IP address for the target MICRO/I.

■ Target Port Number

Specify the port number for the target MICRO/I to execute this function.
