4 Creating and Deleting Data for Recipes
18-18 WindO/I-NV4 User’s Manual
4 Specify the drive for the external memory device, then click OK.
■ Drive
Specifies the drive assigned to the external memory device.
■ Network
Displays the Map Network Drive dialog box. This dialog box allows you to specify a drive on the network.
■ External Memory Device Folder
Specifies the folder to save the created recipe file.
Click to display the Project Settings dialog box. You can specify the External Memory Device folder used as the
save destination.
5 Click OK.
The Recipe Settings dialog box closes.
The “RECIPE” folder is created in the External Memory Device folder used as the save destination, and the recipe files
for the channels configured with Access to set to External Memory Device and Recipe Function set to Enable
in the Recipe Settings dialog box are created.
To Next Page
