WindO/I-NV4 User’s Manual 35-5
1 HG2J-7U
35
MICRO/I Specifications
â– Performance Specifications
â– EMC Specifications
*2 Please be aware that small black and bright dots might show up on LCD Screen: it is not a failure or malfunction.
*3 The life of the LCD itself at an ambient temperature of 25°C. This is not a guaranteed value. The actual life depends on the
environment and conditions of use.
*4 It is a protection structure for the operating surface of HMI, which is attached to a panel. Although protection structure
suffices every test conditions, it does not guarantee to operate under all of the environmental condition.
As for IP65F/IP66F/IP67F oilproof structure, it suffices oilproof test conditions. Conditions are listed in the document that
comes with Japanese Industrial Standard JIS C 0920.
Protection structure do not gurantee usage under long exposure to oil or usage of oil that is not prescribed in the document.
Please test/check beforehand to avoid trouble.
IP ratings are not applicable to UL certification.
*5 If the power is interrupted for more than 20 days, the error message "Backup data lost" will be displayed at the next startup,
and the clock data will be initialized to 00:00:00 on January 1, 2000.
Display
LCD Type
*2
TFT color LCD (TN Type)
Display Colors 65536 Colors
Effective Display Area 154.08 (W) × 85.92 (H) mm
Display Resolution 800 (W) × 480 (H) dots
Dot pitch 0.1926 (W) x 0.179 (H) mm
View angle Left/Right/Top: 80°, Bottom: 60°
Brightness of LCD only
Typ. 500 cd/m
2
Brightness Adjustment 48 levels
Backlight LED
Backlight Life
*3
Approx. 50,000 hours (The time until brightness becomes 50% of the initial value)
Touch
Panel
Switch Type Projected Capacitive
Multiple Operations Possible (2-point touch)
User Memory Approx. 24 MB
Backup of the real-time clock at
25 °C
Typ. 20 days
*5
Backup Data Calendar, Log Data, HMI Keep Relays, HMI Keep Registers
Buzzer output Single tone (tone length is adjustable)
Degree of Protection
*4
When panel thickness is 1 to 5 mm: IP65F (IEC60529)
When panel thickness is 1.6 to 5 mm: IP66F, IP67F (IEC60529), TYPE 4X (indoor use
only), TYPE 13
Weight (approx.) 500g
Radiated Emission
Class A : 10m
40dBµV/m quasi-peak (30M to 230MHz)
47dBµV/m quasi-peak (230M to 1GHz)
Class A : 3m
76dBµV/m (Peak), 56dBµV/m (AVG) (1G to 3GHz)
80dBµV/m (Peak), 60dBµV/m (AVG) (3G to 6GHz)
Electrostatic Discharge Contact : ±6kV Air : ±8kV
Electromagnetic Field
10V/m (80M to 1.0GHz)
3V/m (1.4G to 2.0GHz)
3V/m (2.0G to 2.7GHz)
3V/m (2.7G to 6.0GHz)
80% AM (1kHz)
Fast Transient Burst Power : ±2kV Communication cable : ±1kV
Surge Immunity ±500V (between +24V and 0V) ±500V (between +24V and FE, 0 and FE)
Conducted Radio
Frequency Immunity
3V (Power, Communication cable) (150k to 80MHz)
80% AM (1kHz)
To Next Page
