IDEC WindO/I-NV4

3 Analog I/O Modules
30-26 WindO/I-NV4 User’s Manual
If the setting value is outside the range, a parameter setting error will occur.
■ Data Type
If the setting value is 4 to 65,535, a parameter setting error will occur.
■ Min., Max.
The values of Min. and Max. can be set only when Data Type is set to Optional range. Set the minimum and
maximum values between -32,768 and 32,767. However, when Signal Type is set to PTC Thermistor (threshold),
set the values of Min. and Max. between 100 and 10,000.
■ Filter
The setting value is rounded by 50.
When 50,001 to 65,535 is stored for the setting value, the filter operates as the maximum value of 50,000
milliseconds.
■ Thermistor constant
17 Ni1000
18 NTC Thermistor
19 PTC Thermistor
20 PTC Thermistor (threshold)
21 Ohm meter
22 Expansion 0 to 20mA DC
23 Expansion 4 to 20mA DC
Setting Value Signal Type
Setting Value Data Type
0 Binary data, Binary data (12bit)
1 Optional range, Optional range (12bit)
2 Celsius (℃), Resistance (Ω), Binary data (16bit)
3 Fahrenheit (℉), Optional range (16bit)
Setting Value Filter
0 0 msec
50 50 msec
100 100 msec
150 150 msec
… …
50,000 50,000 msec
Range Thermistor Constant
0 to 65,535 R0
-32,768 to 32,767 T0
-32,768 to 32,767 B
